Garrett G25 550 A/R 0,72 Wastegate
Regular price:
Regular price:
product unavailable
0
Description
Garrett G25-550 A/R 0,72 Wastegate
G-Series G25-550 turbochargers from Garrett are compatible with 1.4L – 3.0L engine displacements and capable of producing up to 550 horsepower.
G25-550 Series turbochargers are smaller and outflow all comparable products on the market. Improved durability with better materials can withstand higher temperatures and better safety margins.
The Garrett G-Series G25-550 turbochargers deliver more power and durability in a smaller frame than ever before.
Horsepower: 300 - 550HP
Displacement: 1.4 - 3.0L
Compressor
Exducer: 60mm
Inducer: 48mm
Trim: 65
Material: Forged Billet Aluminum Alloy
A/R: 0.70
Max Flow: 50 lb/min
Max Recommended Speed: 185000 RPM
Compressor Housing Connections
Inlet: 3.0″ Hose Coupler
Outlet: 2.0″ Hose Coupler
Turbine
Exducer: 49mm
Inducer: 54mm
Trim: 84
Material: Mar-M
A/R: 0.72
Max Temp: 1050C / 1922F
Wastegate: Yes 0.5 bar
Divided: No
Turbine Housing Connections
Inlet: 3.0" V-band
Outlet: 3.5" V-band
Safety
Do you need installation?
Contact with us and we will help you!
